Model
|
ZD-C01
|
ZD-C01 Pro
|
|
sensor
|
1/2.9 "CMOS sensor
|
1/1.8-inch CMOS sensor
|
|
Horizontal resolution
|
1800 TVL
|
1800 TVL
|
|
pixel size
|
2.8 micrometers
|
2.8 micrometers
|
|
Image ratio
|
16:9
|
4:3/16:9
|
|
Video format
|
PAL/NTSC optional
|
PAL/NTSC optional
|
|
Field of view/ white balance
|
FOV:H95 ° V53 °
|
FOV:H88 ° V68 °
|
|
Electronic shutter
|
automatic
|
automatic
|
|
Minimum illumination
|
F1.0/0.00001 Lux
|
F1.0/0.0001Lux
|
|
lens
|
8 giant
|
8 giant
|
|
Operating voltage range
|
5V-40V
|
5V-40V
|
|
Noise Cancellation
|
3D
|
3D
|
|
OSD Menu
|
support
|
support
|
|
size
|
9mm * 19mm * 27mm
|
29mm * 19mm
|
|
Operating current
|
40mA @ 12V
|
60mA @ 12V
|
|
WDR
|
Super WDR (HDR)
|
Super WDR (HDR
|
